7.1.5. Cover fastening screw on the front side
The cover fastening screw (Fig. 9, pos. 6) secures the cover to the chassis on the front side.
To remove the cover of the KISS 2U V2 platform, the following knurled screws have to be loosened:
The cover fastening screw (Fig. 9, pos. 6) on the front side
Fig. 13, pos. 3 and Fig. 15/Fig. 16, pos. 6) on the rear side.
The chassis of the KISS 2U V2 platform is properly closed only if the cover is attached and the above
mentioned screws are fastened.
7.1.6. Filter Mat and Filter Mat Holder
The filter mat and the filter mat holder (Fig. 9, pos. 3) are located behind the air grilles of the front access door (Fig. 7,
pos. 3, pos. 4). The filter mat holder is fastened to the fan slide-in module (Fig. 38, pos. 4) by a knurled screw
(Fig. 38, pos. 5). The filter mat is inserted in the filter mat holder (Fig. 34). This filter mat protects your system against
dust and dirt (see section 10.2 “Cleaning the Filter Mat”).
7.1.7. Fan Slide-in Module
The two system fans are integrated in a user-friendly, replaceable fan slide-in module (see subsection 7.2.6 “Fan Slide-In
Module and Temperature Sensor”). The fan slide-in module (Fig. 9, pos. 2) can be replaced as described in the section
10.1 “Replacing System Fans”.
7.1.8. Drive Bays
Depending on the ordered system configuration, your KISS 2U V2 can be equipped with up to two drive bays (see (Fig. 9,
pos. 8 and 9; configuration with an internal HDD):
Drive Bay
Description (refer to Fig. 9)
one externally accessible 5.25" drive bay (shown with 1x 3.5" removable HDD installed)
L1
L2
one internal 3.5" drive bay for a SATA HDD (shown with an internal, not externally accessible
HDD installed)
or
a front accessible 5.25" slim-line drive bay
or
a CF Reader
For KISS 2U V2 system configurations with a disk subsystem KISS DA 235CF, the drive bays L1 and L2
are occupied by this subsystem with removable HDDs.
For customer-specific versions and system configurations, please refer to the corresponding
“KISS 2U V2 Systems - Configur
.
The KISS Hot Swap disk subsystems allow replacing of the SATA HDDs during operation.
