» USB 7 port hub.
» SATA MO-300 site.
» Mini-PCIe sites (2) with shared SIM slot.
» PCIe slot.
» GbE port with integrated magnetics.
» On-board I2S Audio Codec.
» RS232 support for all 4 SMARC serial ports.
» CAN Bus support (2).
» Micro SD Card slot.
» eMMC Mezzanine site.
» Micro SD Card slot.
» Camera Mezzanine site.
» AFB (Alternate Function Block) site.
» I/O Mezzanine site.
» RTC backup power sources – Lithium coin cell socket and SuperCap option.
» On-board accelerometer.
» SIM card support.
» Lab bench power input option – 3.0V to 5.25V input voltage range.
» Support for Li-Ion batteries and on-board charging circuit.
» Loop-back features for test on selected interfaces.
» Carrier cutout allows access to back side of Module for Module debug.
2.5 Document and Standards References
2.5.1 External Industry Standard Documents
» CAN (“Controller Area Network”) Bus Standards – ISO 11898, ISO 11992, SAE J2411.
» CSI-2 (Camera Serial Interface version 2) The CSI-2 standard is owned and maintained by the MIPI Alliance
(“Mobile Industry Processor Alliance”) ( www.mipi.org ).
» eMMC (“Embedded Multi-Media Card”) the eMMC electrical standard is defined by JEDEC JESD84-B45 and the
mechanical standard by JESD84-C44 ( www.jedec.org ).
» GBE MDI (“Gigabit Ethernet Medium Dependent Interface”) defined by IEEE 802.3. The 1000Base-T
operation over copper twisted pair cabling defined by IEEE 802.3ab (
www.ieee.org ).
» HDMI Specification, Version 1.3a, November 10, 2006 © Hitachi and other companies ( www.hdmi.org ).
» The I2C Specification, Version 2.1, January 2000, Philips Semiconductor (now NXP) ( www.nxp.com ).
» I2S Bus Specification, Feb. 1986 and Revised June 5, 1996, Philips Semiconductor (now NXP)
( www.nxp.com ).
» JEDEC MO-300 (mSATA) defines the physical form factor of the mSATA format ( www.jedec.org ). The electrical
connections are defined in the Serial ATA document.
