20 Appendix B: Assembly Part Numbers
Item Description
PCB
Number
Assembly Number
Orderable Part
Number
SMARC Evaluation Carrier
501-146-A0 701-188
51000-0000-00-0
SMARC Development Kit
51000-0000-00-S
SMARC eMMC Mezzanine
501-151-A0 701-199
SMARC KLAS Hyundai (HD-1366G768-101MTW)
501-162-A0 701-215
Hyundai HD-1366G768-101MTW Display
Cable for Hyundai (HD-1366G768-101MTW) 10” FFC
1052-7352
SMARC KLAS NEC (NL12876AC18-03)
501-163-A0 701-216
Cable for NEC (NL12876AC18-03) 10”
420-0039-00
NEC NL12876AC18-03 Display
SMARC Hy-Line KLAS (Hy-Line PM070WL4)
501-164-A0
Cable for Hy-Line (Hy-Line PM070WL4)
SMARC VESA Standard KLAS
501-165-A0
SMARC I/O Mezzanine
NA
SMARC Camera Mezzanine
NA
SMARC AFB Mezzanine
NA
Serial Port (w DB9 connectors)
423-0549-00
microUSB to USB type A
423-0556-00
Battery connector pigtails
423-0546-00
Charger connector pigtails
423-0547-00
Test Bench connector pigtails
423-0548-00
LCD Backlight power pigtails
423-0551-00
Audio Line in pigtails
423-0553-00
Audio Line out pigtails
423-0553-00
Speaker pigtails
423-0552-00
SPDIF pigtails
423-0555-00
