53 GPIO3/CAM1_RST# 54 GND
55 GPIO4/HDA_RST# 56 WDT_TIME_OUT#
57 GPIO5/PWM_OUT 58 PCIE_WAKE#
59 GPIO6/TACHIN 60 SLEEP#
61 GPIO7/PCAM_FLD 62 CARRIER_STBY#
63 GPIO8/CAN0_ERR# 64 RESET_OUT#
65 GPIO9/CAN1_ERR# 66 RESET_IN#
67 GPIO10 68 GND
69 GPIO11 70 SER0_TX
71 GND 72 SER0_RX
73 SPDIF_OUT 74 SER0_RTS#
75 SPDIF_IN 76 SER0_CTS#
77 V_IO 78 SER1_TX
79 V_IO 80 SER1_RX
81 GND 82 SER0_1_MEZ_KILL#
83 1.8V 84 GND
85 1.8V 86 SER2_TX
87 GND 88 SER2_RX
89 3.3V 90 SER2_RTS#
91 3.3V 92 SER2_CTS#
93 GND 94 SER3_TX
95 5.0V 96 SER3_RX
97 5.0V 98 SER2_3_MEZ_KILL#
99 5.0V 100 NC
