19 Appendix A: Connector Mating Part Number Information
Connector
Reference
Kontron PN
Mfg
MPN
Qty
Description
Mating Connector
PN
Ref Des
Li-Ion Battery
1052-4601
TE Conn
2-292173-6
3
Header, 4-pin, SMT
173977-6
J23,J24,J25
Battery
Charger Input
1046-5609
MOLEX
39-30-3035
1
Mini-Fit Jr., 3-pin, RA,
Header
39-01-4030
Crimp Terminal
45750
J28
Test Bench
Power Input
1051-5020
MOLEX
39303045
1
Mini-Fit Jr., 4-pin, RA,
Header
39-01-4040
Crimp Terminal
45750
J29
KLAS
Connector
1052-2683
Hirose
FX12B-60S-
0.4SV
2
Receptacle, 60-pin,
SMT
FX12B-60P-0.4SV
J31,J32
HDMI
1050-0849
FCI
10029449-
001TLF
1
HDMI Receptacle, RA,
SMT
NA
J30
RS232 Header
1046-3583
JST
SM05B-SRSS-
TB(LF)(SN)
4
Header, Shrouded, 5-
pin, SMT
SHR-05V-S-B
Crimp terminal
SSH-003T-P0.2-H
J18,J19,J20,J2
1
Headphone
TRS Jack
1051-5812
CUI
SJ-43514
1
Audio Jack, 4-pin, PTH
NA
J7
MIC TRS Jack
1051-5812
CUI
SJ-43514
1
Audio Jack, 4-pin, PTH
NA
J6
USB Type A
(single)
1051-5324
TE Conn
292303-4
1
Conn USB RCP 4 POS
Solder RA
NA
J3
USB Type A
(dual-stacked)
1045-1459
FCI
72309-
7024BLF
1
USB-A, Dual-stacked,
RA, PTH
NA
J1, J4
USB micro AB
OTG
1046-5754
Molex
475900001
1
USB-AB, RA, SMT
NA
J2
GBE RJ45
1045-4258
Bel Fuse
L829-1J1T-43
1
RJ45, 1-port, SMT
NA
J5
Camera
Mezzanine
1052-2681
Hirose
FX12B-60P-
0.4SV
1
Plug, 60-pin, SMT
FX12B-60S-0.4SV
J43
AFB Mezzanine
1052-2542
Samtec
QSH-020-01-L-
D-DP-A
1
High Speed Socket. 20
Diff Pairs
QTH-020-01-L-D-
DP-A
J41
Boot Select
Jumper
1051-5515
FCI
77311-118-
02LF
13
Header, 2-pin, PTH
NA
J26,J27,J34,J3
5,J36,J37,J38,J
39,J49,J55,J56
