Kontron microETXexpress-PV User’s Guide
www.kontron.com
63
Menu Bar
The menu bar at the top of the window lists different menus. Use the
← arrow
key or the
→ arrow key to make a selection.
Legend Bar
Use the keys listed on the bottom of the legend bar to make your selections
or exit the current menu. The table below describes the legend keys and their
alternates.
Key Function
Shows the General Help window
Exit menu.
← or → Arrow key Select a menu.
↑ or ↓ Arrow key Select fields in current menu.
or Move cursor to top or bottom of current
window.
or Move cursor to next or previous page.
Load Optimal Defaults.
Save and exit.
Execute command or select submenu.
Refresh screen.
Change Colors
Discard Changes
Load Failsafe Defaults
Selecting an Item
Use the
↑ or ↓ key to move the cursor to the field you want. Then use the +
and – keys to select a value for that field. The Save Value commands in the
Exit menu save the values displayed in all the menus.
Displaying Submenus
Use the
← arrow key or the → arrow key to move the cursor to the submenu you
want and then press . A pointer ( ) marks all submenus.
Item Specific Help Window
The Help window on the right side of each menu displays the Help text for the
selected item. It updates as you move the cursor through each field.
General Help Window
