Kontron COMe-cPV2(v1.0) User Manual
Page 27

Kontron microETXexpress-PV User’s Guide
www.kontron.com
23
Pin
Signal
Description
Type
Terminati
on
Comment
B42
USB3-
USB Data- Port #3
DP-I/O
-
Hooked to USB
port #3 on the
ICH8M.
B43
USB3+
USB Data+ Port #3
-
B44
USB_0_1_OC#
USB Over current
Pair 0/1
I-3.3 SUS
PU 3.3
SUS of
10K
Hooked to over
current pin 0/1
of ICH8M.
B45
USB1-
USB Data- Port #1
DP-I/O
-
Hooked to USB
port #1 on the
ICH8M.
B46
USB1+
USB Data+ Port #1
-
B47
EXCD1_PERST#
PCIe Express Card
1 Reset
O-3.3
-
Connected to
ICH8M pin
GPIO6.
B48
EXCD1_CPPE#
PCIe Express Card
1 Request
I-3.3
PU 3.3 of
10K
Connected to
ICH8M pin
GPIO12.
B49
SYS_RESET#
Reset button
input
I-3.3
PU 3.3
SUS of
10K
-
B50
CB_RESET#
Carrier Board
Reset
O-3.3 SUS
-
-
B51
GND (Fixed)
Power Ground
PWR
-
-
B52
PCIE_RX5+
PCIe 5 Receive
Data+
Not
connected
nc
nc
B53
PCIE_RX5-
PCIe 5 Receive
Data-
Not
connected
nc
nc
B54
GPO1
General Purpose
Output 1
O-3.3
-
Connected to
CPLD
B55
PCIE_RX4+
PCIe 4 Receive
Data+
DP-I
-
-
B56
PCIE_RX4-
PCIe 4 Receive
Data-
-
-
B57
GPO2
General Purpose
Output 2
O-3.3
-
Connected to
CPLD
B58
PCIE_RX3+
PCIe 3 Receive
Data+
DP-I
-
-
B59
PCIE_RX3-
PCIe 3 Receive
Data-
-
-
B60
GND (Fixed)
Power Ground
PWR
-
-
B61
PCIE_RX2+
PCIe 2 Receive
Data+
DP-I
-
B62
PCIE_RX2-
PCIe 2 Receive
Data-
-
B63
GPO3
General Purpose
Output 3
O-3.3
Connected to
CPLD
B64
PCIE_RX1+
PCIe 1 Receive
Data+
DP-I
-
-
