Kontron microETXexpress-PV User’s Guide
www.kontron.com
36
4.1.4
Connector J4 - XDP
The eXtended Debug Port (XDP) connector is a 24-pin connector used for
debugging the board.
NOTE: This connector is for development debug purposes only. The XDP
connector pin-out is under NDA.
4.1.5
Connector J5 –JTAG
This is the Intel® ICH8M debug connector.
WARNING: The debug port is for internal use only. Do not connect any devices.
Table 8: J5 JTAG Connector Pin-Out
Pin
Name
Termination
1
V_3V3_S5
-
2
CPLD_TDI
PU to 3.3V SUS of 1K.
3
CPLD_TCK
PD to 1K.
4
CPLD_TMS
PU to 3.3V SUS of 1K.
5
CPLD_TDO
PU to 3.3V SUS of 1K.
6
GND
-
7
KILL_POWER_UP#
PU 5K to 25K in the
CPLD.
8
GND
-
4.1.6
SSD Mezzanine Connector (optional)
The optional onboard SSD module interface uses SATA to connect to port 2 the
Intel® ICH8M.
Table 9: J6 SSD Connector Pin-Out
Pin
Name
1
GND
2
GND
3
GND
4
SATA_RX+
5
V_3V3
6
SATA_RX-
7
V_3V3
8
GND
9
V_3V3
10
SATA_TX+
11
NC
12
SATA_TX-
13
RESET
