Pin Signal Description Type Terminati
on
Comment
Clock 10K ohms
A84 LVDS_I2C_DAT LVDS Display I
2
C
Data
I/OD-3.3
PU 3.3 of
10K ohms
A85 GPI3 General Purpose
Input 3
I-3.3
PU 3.3 of
10K ohms
Connected to
CPLD
A86 KBD_RST# Keyboard Reset
I-3.3
PU 3.3 of
10K ohms
5V tolerant
input
A87 KBD_A20GATE A20 gate
I-3.3
PU 3.3 of
10K ohms
A88 PCIE0_CK_REF+ PCIe Clock
(positive)
DP-O
- -
A89 PCIE0_CK_REF- PCIe Clock
(negative)
- -
A90 GND (Fixed) Power Ground PWR - -
A91 SPI_POWER SPI Power PWR; 3.3
SUS
- -
A92 SPI_MISO SPI Data In
I – 3.3 SUS
PU 3.3 of
15K to
35K ohms
-
A93 GPO0 General Purpose
Output 0
O - 3.3
Connected to
CPLD
A94 SPI_CLK SPI Clock O – 3.3 SUS
A95 SPI_MOSI SPI Data Out
A96 GND (FIXED) Power Ground PWR - -
A97 TYPE10# Not connected for
Type 2 Rev 2.0
modules
nc
- -
A98 RSVD Reserved nc - -
A99 RSVD Reserved nc -
A10
0
GND (Fixed) Power Ground
PWR
- -
A10
1
RSVD Reserved
nc
- -
A10
2
RSVD Reserved
nc
- -
A10
3
RSVD Reserved
nc
- -
A10
4
VCC_12V 12V VCC
PWR
- -
A10
5
VCC_12V 12V VCC
PWR
- -
A10
6
VCC_12V 12V VCC
PWR
- -
A10
7
VCC_12V 12V VCC
PWR
- -
A10
8
VCC_12V 12V VCC
PWR
- -
A10
9
VCC_12V 12V VCC
PWR
- -
