Kontron microETXexpress-PV User’s Guide
www.kontron.com
16
Type Description
DP-I/O Differential Pair Input/Output
DP-I Differential Pair Input
DP-O Differential Pair Output
PU Pull-Up Resistor
PD Pull-Down Resistor
PWR Power Connection
nc Not connected, Signal not available
NOTE: To protect external power lines of peripheral devices, make sure
that the wires have the right diameter to withstand the maximum
available current and the enclosure of the peripheral device fulfils
the fire-protection requirements in IEC/EN60950
4.1 Pin-Outs
4.1.1 Connectors X1A and X1B: microETXexpress® Interface
Table 3: Connector X1A - Row A
Pin Signal Description Type Terminati
on
Comment
A1 GND(Fixed) Power Ground PWR - -
A2 GBE0_MDI3- Ethernet I/O
Data-
DP-I/O
- -
A3 GBE0_MDI3+ Ethernet I/O
Data+
- -
A4 GBE0_LINK100# Ethernet Speed
LED 100Mbps
OD-
3.3/3.3 SUS
- On at 100 Mbps
A5 GBE0_LINK1000# Ethernet Speed
LED 1000Mbps
OD-3.3/3.3
SUS
- On at 1000
Mbps
A6 GBE0_MDI2- Ethernet I/O
Data-
DP-I/O
- -
A7 GBE0_MDI2+ Ethernet I/O
Data-
- -
A8 GBE0_LINK# LAN Link LED OD –
3.3/3.3 SUS
- -
A9 GBE0_MDI1- Ethernet I/O
Data-
DP-I/O
- -
A10 GBE0_MDI1+ Ethernet I/O
Data-
- -
A11 GND (Fixed) Power Ground PWR - -
A12 GBE0_MDI0- Ethernet I/O
Data-
DP-I/O
- -
A13 GBE0_MDI0+ Ethernet I/O
Data-
- -
A14 GBE0_CTREF LAN Reference
Voltage
O-1.9/1.9
SUS
- -
