Kontron microETXexpress-PV User’s Guide
www.kontron.com
58
I/O Address Used for Availa
ble
Comment
0090 – 009F System Resources No Fixed
00A0 - 00BF Interrupt Controller 2 No Fixed
00C0 - 00DF DMA Controller 2 No Fixed
00E0 - 00EF System Resources No Fixed
00F0 - 00FF Math Coprocessor No Fixed
0170 – 0177
0376
Fixed Disk No Available if IDE
port 1 is disabled
01F0 - 01F7
03F6
Fixed Disk No Available if IDE
port 1 is disabled
0290-0295 ADT7476 HWM No SMBus driven
03B0 - 03DF VGA No Fixed
03F8 – 03FF Serial port 1 No Available if
WB83627HG is
disabled.
0400 - 041F SMBus No Fixed
04D0 - 04D1 PIC Extension No Fixed
0500 – 053F GPIO No Fixed
0A20 – 0A2F SIO Hardware Monitor No Fixed if SIO is in
system
0A05 – 0A06 ADT7476
Hardware Monitor
No The HW monitor uses
the SMBus to access
registers (address
is 0x5C)
0A00 – 0A1F CPLD No CPLD use 0A00h to
0A1Fh
0D00 - FFFF PCI Bus No Fixed
C000 – C007 VGA No Fixed
C400 – C41F Standard PCI to USB No Dynamic
C480 – C49F USB Host Controller 2832 No Dynamic
C800 – C81F USB Host Controller 2831 No Dynamic
C880 – C89F USB Host Controller 2830 No Dynamic
D000 - DFFF PCIe Root Port 1 No Dynamic (BIOS
default value)
E000 - EFFF PCIe Root Port 2 No Dynamic (BIOS
default value)
0CF8 - 0CFF PCI Configuration No Fixed
FF90 - FFAF SATA Controller No Dynamic (BIOS
default address)
7.4 Peripheral Component Interconnect (PCI) Devices
All devices follow the Peripheral Component Interconnect 2.3 (PCI 2.3) and
the PCI Express Base 1.0a specifications. The BIOS and OS control memory and
I/O resources. Please see the PCI 2.3 specification for details.
