2 functional block diagram, Functional block diagram – Kontron COMe-cPV2(v1.0) User Manual
Page 13
Kontron microETXexpress-PV User’s Guide
www.kontron.com
9
»
HWM:
Temperature monitoring for CPU and board temperature
(external ON Semiconductor ADT7476 hardware monitor)
»
Passive Cooling: Passive and Critical Trip Point
»
ACPI:
ACPI 3.0
»
S-States:
S0, S3, S4, S5
»
Input Voltage: Single supply support with wide range power supply input,
4.75V – 18V
The 5.0V supply is the standby power rail.
3.2
Functional Block Diagram
Figure 1 is the microETXexpress®-PV-XT COM block diagram
Figure 1: microETXexpress®-PV-XT COM Block Diagram
