option “GbE Controller” is
set to “Enabled”
GbE Wake up
From S5
Enabled
Disabled
Allows PME_B0_EN in
chipset registers
Used to enable GbE to wake
system from S5
Wake On LAN S3-
S5
Enabled
Disabled
Allows WOL on the GbE chip
HDA Controller Enabled
Disabled
Enables or disables the
High Definition Audio
device
SMBus Controller Configuration
Feature Option Description
SMBUS
Controller
Enabled
Disabled
Enables or disables the
SMBus controller.
BDF(0,1F,3)
SLP_S4# Min.
Assertion Width
Disabled
4 to 5
seconds
3 to 4
seconds
2 to 3
seconds
1 to 2
seconds
Enables or diables setting
a delay of seconds before
the SLP_S4# signal
Used to guarantee that the
DRAMs have been safely
power-cycled
PCIE Port 0 Auto Enables or disables the
