Display Interfaces

VGA:

The maximum resolution supported is 2048 x 1536 @ 60Hz

Flat Panel:

Single Channel LVDS 18bit

resolution up to 1366 x 768 (WXGA)

Storage

SATA:

3xSATA ports supporting up to 1.5 Gbps (SATA150) and 3.0

Gbps (SATA300) transfer rate

PATA (IDE):

1x Parallel ATA (PATA)

supports ATA transfer mode up to

Ultra DMA 5 at 100MB/s.

Onboard Devices:

Ethernet:

Intel® 82567LM 10/100/1000 Mbit Ethernet Controller

The 82567LM is only a PHY; the MAC is in the ICH. It is

connected to the GLCI and LCI interfaces of the ICH8M.

Ethernet Features:

WakeOnLAN, PXE Lanboot,

TPM:

AT97SC3204 TPM from Atmel

Watchdog Timer: BIOS enables and configures watchdog in the CPLD.

Watchdog has the option to generate NMI after the delay has

expired.

PCI:

The PCI 32-bit 33 MHz interface from the ICH (rev. 2.3

compliant) is connected to the COM Express connector

Power Management:

BIOS enables ACPI power management revision 3.0 for

supported OS.

BIOS enables SpeedStep Technology

Additional Interfaces:

LPC bus:

Yes, to COM Express A-B connector

SMBus:

Yes, to COM Express A-B connector

Yes, fast I

C (from Intel® ICH8M)

GPIO:

4x GPI and 4x GPO

SPI

Yes, to COM Express A-B connector

JIDA:

Yes, JIDA EEPROM

JIDA BIOS support

JILI BIOS support

AMI AMIBIOS8 Core BIOS

K-Station:

Yes

Bootlogo:

Yes

MARS:

Supported for smart battery management
