KTHM65 Users Guide
KTD-N0838-A Page 7
Introduction
This manual describes the KTHM65/mITX board made by KONTRON Technology A/S.
The KTHM65 board is based on KTQM67/mITX design, where the chipset QM67 is replaced by HM65,
having less functionality. The KTHM65 support 2 nd and 3 rd generation Intel® i7 -, i5 -, i3 2Core and
4Core processor and the Celeron B810 2Core, see “Processor Support Table for more specific details.
The difference between the KTHM65/mITX and the KTQM67/mITX is specified in the following table:
Function KTHM65/mITX KTQM67/mITX
Chipset HM65 QM67
LAN ETH1 ETH1 + ETH2 + ETH3
Display support DVI-I - 2x DP - LVDS DVI-I - 2x DP - LVDS - eDP
IEEE1394a - IEEE1394_0 - IEEE1394_1
USB 6 External + 6 Internal 6 External + 8 Internal
RAID - RAID 0/1/5/10
Intel® AMT - AMT 7.0
Intel® TXT - Yes *
Intel® VT-d - Yes *
Intel® vPRO - Yes *
Intel® Remote PC Assist Technology Reactive Proactive - Reactive
(*) Depends also on processor type.
Use of this Users Guide implies a basic knowledge of PC-AT hard- and software. This manual is
focused on describing the KTHM65 board’s special features and is not intended to be a standard PC-AT
textbook.
New users are recommended to study the short installation procedure stated in the following chapter
before switching-on the power.
All configuration and setup of the CPU board is either done automatically or manually by the user via
the CMOS setup menus. Only exception is the “Load Default BIOS Settings” Jumper.
