KTHM65 Users Guide
KTD-N0838-A Page 57
6.1.4 PCI-Express x1 Connector (PCIe x1) (J36)
The KTHM65 support one PCIe x1.
Note 1: 10K ohm pull-up to 3V3 Dual.
Note 2: 4K7 ohm pull-down to GND.
Note Type Signal PIN Signal Type Note
PWR +12V B1 A1 GND PWR
PWR +12V B2 A2 +12V PWR
PWR +12V B3 A3 +12V PWR
PWR GND B4 A4 GND PWR
SMB_CLK B5 A5 CL_CLK
SMB_DATA B6 A6 CL_RST
PWR GND B7 A7 SMB_ALERT
PWR +3V3 B8 A8 CL_DATA
2 JTAG_TEST# B9 A9 +3V3 PWR
PWR 3V3 Dual B10 A10 +3V3 PWR
WAKE# B11 A11 RST#
NC NC B12 A12 GND PWR
PWR GND B13 A13 PCIE_CLK_P
PCIE_TXP B14 A14 PCIE_CLK_N
PCIE_TXN B15 A15 GND PWR
PWR GND B16 A16 PCIE_RXP
1 CLK_REQ B17 A17 PCIE_RXN
PWR GND B18 A18 GND PWR
