9.3.2.3 NB PCIe Configuration
Note: PCIe PEG Bifurcation is not supported on KTHM65/mITX.
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0
PEG0 – Gen X
PEG0 ASPM
PCIe PEG Bifurcation
Enable PEG
Detect Non-Compliance Device
De-emphasis Control
PEG Sampler Calibrate
Swing Control
PEG Link Disabled
Fast PEG Init
RxCEM Loop back
Not Present
[Auto]
[Disabled]
[1 x16]
[Auto]
[Disabled]
[-3.5 dB]
[Auto]
[Full]
[Disabled]
[Enabled]
[Disabled]
Configure PEG0 B0:D1:F0
Gen1-Gen2
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1226. Copyright © 2012 American Megatrends, Inc
BIOS - Chipset
