2 system overview, System overview, System specification – Kontron KTHM65-mITX User Manual
Page 14
KTHM65 Users Guide
KTD-N0838-A Page 14
2.2 System overview
The block diagram below shows the architecture and main components of the KTHM65. The key
component on the board is the Intel
®
QM67 (Cougar Point) Mobile Express Chipset.
Some components (PCI slots) are optional depending on board type.
More detailed block diagram on next page.
System Specification
