Page 62
KTHM65 Users Guide
KTD-N0838-A Page 62
8.4 IO Map
Address range (hex)
Size (hex) Description
0x0000FFFF 0x0000FFFF
1 Motherboard resources
0x0000F0D0 0x0000F0D7
8 Intel® 6 port SATA AHCI – 1C03
0x0000F0C0 0x0000F0C3
4 Intel® 6 port SATA AHCI – 1C03
0x0000F0B0 0x0000F0B7
8 Intel® 6 port SATA AHCI – 1C03
0x0000F0A0 0x0000F0A3
4 Intel® 6 port SATA AHCI – 1C03
0x0000F060 0x0000F07F
20 Intel® 6 port SATA AHCI – 1C03
0x0000F040 0x0000F05F
20 Intel® SMBus – 1C22
0x0000F000 0x0000F03F
40 Intel® HD Graphics family
0x0000E000 0x0000EFFF
1000 Intel® PCIe Root port 3 – 1C14
0x0000D000 0x0000DFFF
1000 Intel® PCIe Root port 4 – 1C16
0x0000164E 0x0000164F
2 Motherboard resources
0x00000F78 0x00000F7F
8 Motherboard resources
0x00000D00 0x0000FFFF
F300 PCI bus
0x00000B78 0x00000B7F
8 Motherboard resources
0x00000A00 0x00000A2F
30 Motherboard resources
0x00000778 0x0000077F
8 Motherboard resources
0x00000680 0x0000069F
20 Motherboard resources
0x00000500 0x0000057F
80 Motherboard resources
0x000004D0 0x000004D1
2 Programmable interrupt controller
Motherboard resources
0x00000458 0x0000047F
28 Motherboard resources
0x00000454 0x00000457
4 Motherboard resources
0x00000400 0x00000453
54 Motherboard resources
0x000003F8 0x000003FF
8 COM1
0x000003E8 0x000003EF
8 COM4
0x000003C0 0x000003DF
20 Intel® HD Graphics family
0x000003B0 0x000003BB
C Intel® HD Graphics family
0x00000378 0x0000037F
8 Printer port LPT1
0x000002F8 0x000002FF
8 COM2
0x000002E8 0x000002EF
8 COM3
0x00000290 0x0000029F
10 Motherboard resources
0x0000020E 0x0000020F
2 Motherboard resources
0x000000F0 0x000000FF
10 Numeric data processor
0x000000E0 0x000000EF
10 Motherboard resources
0x000000D0 0x000000DF
10 Direct memory access controller
0x000000BE 0x000000BF
2 Motherboard resources
0x000000BC 0x000000BD
2 Programmable interrupt controller
0x000000BA 0x000000BB
2 Motherboard resources
0x000000B8 0x000000B9
2 Programmable interrupt controller
0x000000B6 0x000000B7
2 Motherboard resources
0x000000B4 0x000000B5
2 Programmable interrupt controller
0x000000B2 0x000000B3
2 Motherboard resources
0x000000B0 0x000000B1
2 Programmable interrupt controller
0x000000AE 0x000000AF
2 Motherboard resources
0x000000AC 0x000000AD
2 Programmable interrupt controller
0x000000AA 0x000000AB
2 Motherboard resources
0x000000A8 0x000000A9
2 Programmable interrupt controller
0x000000A6 0x000000A7
2 Motherboard resources
0x000000A4 0x000000A5
2 Programmable interrupt controller
0x000000A2 0x000000A3
2 Motherboard resources
0x000000A0 0x000000A1
2 Programmable interrupt controller
System Resources
