KTHM65 Users Guide
KTD-N0838-A Page 101
9.3.1.1 PCI Express Configuration
Note1: Only visible if “Subtractive Decode” is Enabled.
Note2: To enter number use digit keys and/or +/- keys.
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Chipset
PCI Express Configuration
Subtractive Decode
Subtractive Decode Port#
►
PCI Express Root Port 1
► PCI Express Root Port 2
► PCI Express Root Port 3
► PCI Express Root Port 4
►
PCI Express Root Port 6
► PCI Express Root Port 7
► PCI Express Root Port 8
[Disabled]
0
Enable or disable PCI Express
Subtractive Decode.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1226. Copyright © 2012 American Megatrends, Inc
Function Selection Description
Subtractive Decode
Disabled
Enabled
Enable or disable PCI Express Subtractive
Decode.
Subtractive Decode Port#
(Note1) 0
(Note2) Select PCI Express Subtractive Decode Root
Port. User to ensure port availability.
BIOS - Chipset
