KTHM65 Users Guide
KTD-N0838-A Page 60
8.2 PCI Devices
Bus
#
Device
#
Function
#
Vendor
ID
Device
ID
Chip Device Function
0 0 0 8086 0104 CPU Intel – DRAM Controller
0 2 0 8086 0126 CPU Intel - VGA Controller
0 22 0 8086 1C3A QM67 Chipset Intel - Other communication
0 25 0 8086 1502 82579LM LAN Intel - Ethernet Controller
0 26 0 8086 1C2D QM67 Chipset Intel - USB
0 27 0 8086 1C20 QM67 Chipset Intel - HD Audio
0 28 0 8086 1C10 QM67 Chipset Intel - PCI to PCI bridge 01
0 28 2 8086 1C14 QM67 Chipset Intel - PCI to PCI bridge 02
0 28 3 8086 1C16 QM67 Chipset Intel - PCI to PCI bridge 03
0 28 5 8086 1C1A QM67 Chipset Intel - PCI to PCI bridge 04
0 29 0 8086 1C26 QM67 Chipset Intel - USB
0 31 0 8086 1C4F QM67 Chipset Intel - LPC
0 31 2 8086 1C03 QM67 Chipset Intel - SATA Direct Port
0 31 3 8086 1C22 QM67 Chipset Intel - SMBus
2 0 0 8086 10D3 82574L LAN Intel - Ethernet Controller
3 0 0 8086 10D3 82574L LAN Intel - Ethernet Controller
