KTD-00774-G

KTUS15/mITX

Page 81 of 84

7.7.3 Advanced Chipset Settings – South Bridge Chipset Configuration

BIOS SETUP UTILITY

Chipset

South Bridge Chipset Configuration

Number of UCHI

Ports in system ECHI

ONLY is automatically

Added.

<-> Select Screen

|| Select Item

Enter Go to Sub Screen

F1 General Help

F10 Save and Exit

ESC Exit

USB Functions [6 USB Ports]

USB 2.0 Controller [Enabled]

USB Client Controller [Disabled]

SDIO Controller [Enabled]

Audio Controller Codec [Auto]

Audio Jack Sensing [Auto]

Restore on AC Power Loss [Power on]

V02.63+ (C)Copyright 1985-2008, American Megatrends, Inc.

Feature

Options

Description

USB Functions

Disabled

2 USB Ports

4 USB Ports

6 USB Ports

Disabled: covers all USB ports inclusive USB6/7

2 USB Ports: (USB0/1)

4 USB Ports: (USB0/1/2/3)

6 USB Ports: (USB0/1/2/3/4/5)

USB 2.0 Controller

Disabled

Enabled

(This setting only available if USB Function is not

disabled)

Disabled: Disable USB6/7

Enabled: Enable USB6/7

Note: USB6/7 supports only USB2.0 HiSpeed

(480Mbps)

USB Client Controller

Disabled

Enabled

Disabled

Enabled

SDIO Controller

Disabled

Enabled

Disabled

Enabled

Audio Controller Codec

Auto

Azalia

Disabled

Auto

Azalia

Disabled

Audio Jack Sensing

Auto

Disabled

Auto: The insertion of audiojacks are auto

determined.

Disabled: Driver Assumes that all jacks are inserted

(useful when using the Audio pinrow)

Restore on AC Power Loss

Power Off

Power On

Last State

Power Off

Power On

Last State
