Page 44

KTD-00774-G
KTUS15/mITX
Page 44 of 84
4.17
TPM Connector (TPM)
Note Pull
U/D Ioh/Iol Type
Signal
PIN
Signal
Type Ioh/Iol Pull
U/D Note
-
-
PWR
LPC CLK
1 2
GND
-
-
PWR LPC FRAME#
3
KEY
LPC RST#
5 6
+5V
LPC AD3
7 8
LPC AD2
+3V3
9 10
LPC AD1
LPC AD0
11 12
GND
SMB_CLK
13 14
SMB_DATA
SB3V3
15 16
LPC SERIRQ
GND
17 18
CLKRUN#
SUS_STAT#
19 20
NC
The TPM connector is only used in case the onboard BIOS is corrupted and has to be recovered by use of a
KT-BIOS-Recovery-Module.
