6.4
IO Map
Address range (hex)
Size Description
0
cf7
3320 PCI-bus
10
001f
16 Motherboard resources
20
21
2 Programmable interrupt controller
22
3f
30 Motherboard resources
40
43
4 System timer
44
5f
28 Motherboard resources
60
60
1 Standard Keyboard
61
61
1 System Speaker
63
63
1 Motherboard resources
64
64
1 Standard Keyboard
65
65
1 Motherboard resources
67
6f
9 Motherboard resources
70
71
2 System CMOS/Real time clock
72
7f
14 Motherboard resources
80
80
1 Motherboard resources
84
86
3 Motherboard resources
88
88
1 Motherboard resources
8c
8e
3 Motherboard resources
90
9f
16 Motherboard resources
a0
a1
2 Programmable interrupt controller
a2
bf
30 Motherboard resources
e0
ef
16 Motherboard resources
f0
ff
16 Numeric data processor
170
177
8 Secondary IDE-canal
1f0
1f7
8 Primary IDE-canal
274
277
4 ISAPNP read data port
279
279
1 ISAPNP read data port
2f8
2ff
8 Communications port (COM2)
376
376
1 Secondary IDE-canal
378
37f
8 Printer port (LPT1)
3b0
3bb
12 Intel(R) Graphics Media Accelerator 500
3c0
3df
32 Intel(R) Graphics Media Accelerator 500
3f6
3f6
1 Primary IDE-canal
3f8
3ff
8 Communications port (COM1)
400
43f
64 Motherboard resources
480
4BF
64 Motherboard resources
04D0
04D1
2 Motherboard resources
900
09F3
244 Motherboard resources
0A00
0A0F
16 Motherboard resources
0A10
0A1F
16 Motherboard resources
0A79
0A79
1 ISAPNP read data port
0D00
FFFF
62208 PCI-bus
C000
DFFF
8192 PCI standard PCI to PCI-bridge
C000
DFFF
8192 Intel(R) SCH Family PCI Express Root Port 1 - 8110
C000
DFFF
8192 PCI standard PCI to PCI-bridge
C080
C087
8 Standard Dual Channel PCI IDE
C480
C483
4 Standard Dual Channel PCI IDE
C880
C887
8 Standard Dual Channel PCI IDE
CE80
CE8F
16 Standard Dual Channel PCI IDE
CF00
CF03
4 Standard Dual Channel PCI IDE
D000
DFFF
4096 PCI standard PCI to PCI-bridge
D880
D89F
32 Intel(R) 82574L Gigabit Network Connection
E080
E09F
32 Intel(R) SCH Family USB Universal Host Controller - 8115
E480
E49F
32 Intel(R) SCH Family USB Universal Host Controller - 8114
E880
E887
8 Intel(R) Graphics Media Accelerator 500
EF00
EF1F
32 Intel(R) SCH Family USB Universal Host Controller - 8116
FFA0
FFAF
16 Standard Dual Channel PCI IDE-controller
