986LCD-M Family
KTD-N0837-B Public User Manual Date: 2012-04-17 Page 87 of 91
8.7.2 Advanced Chipset Settings – Video Function Configuration
BIOS SETUP UTILITY
Chipset
Video Function Configuration
Fixed Mode
DVMT Mode
Combo Mode
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
DVMT Mode Select [DVMT Mode]
DVMT/ Fixed Memory [128MB]
Boot Type: [CRT]
Backlight Signal Inversion [Disabled]
LCDVCC Voltage [3.3V]
Backlight PWM modulation [10KHz]
Backlight PWM ratio [50%]
LVDS [None]
SDVO [N/A]
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
DVMT Mode Select Fixed Mode
DVMT Mode
Combo Mode Setup Video memory mode
DVMT/ Fixed Memory 64MB
128MB
Maximum DVMT
Boot Type VBIOS Default
CRT
LFP
CRT+LFP
EFP
TV
CRT+EFP
CRT+TV
EFP+EFP2
EFP+TV
CRT+CRT2
CRT+EFP2 VBIOS: Automatic detection.
CRT: Boot on CRT (onboard VGA CRT)
LFP: Boot on Local Flat Panel (onboard LVDS)
CRT+LFP: Boot on CRT and on LFP
EFP: Boot on External Flat Panel (ADD2-card)
TV: Boot on TV (only available on some boards)
CRT+EFP: Boot on CRT and on EFP
CRT+TV: Boot on CRT and TV
EFP+EFP2: Not supported
EFP+TV: Not supported
CRT+CRT2: Boot on CRT and CRT2 (ADD2-CRT)
CRT+EFP2: Boot on CRT and on EFP2
LCDVCC Voltage 3.3V
5V Select LCDVCC voltage for LVDS connector output
Backlight PWM modulation
1KHz
5KHz
10KHz
20KHz Backlight intensity PWM signal frequency setup
Backlight PWM ratio
0%, 12.5%, 25%
37.5%, 50%, 62.5%
75%, 87.5%, 100% Backlight intensity PWM signal pulse width setup
LVDS (see description ->) Select Resolution, Manufacturer and Type no. for
the actual LVDS display.
SDVO N/A
(see description ->)
DVI-D
DVI-I
CRT N/A: No ADD2 card detected
-> ADD2-LVDS card: select display type.
DVI-D: ADD2-DVI card installed
DVI-I: Not supported
CRT: ADD2-CRT card installed
