986LCD-M Family
KTD-N0837-B Public User Manual Date: 2012-04-17 Page 19 of 91
986LCD-M/mITX with w/1.06GHz Celeron M 512MB test results:
Test Supply Current draw Power consumption
DOS, Idle, mean +12V 0.36A 4.32W
+5V 1.37A 6.85W
+3V3 1.31A 4.323W
-12V 0A 0W
5VSB 0A 0W
Total 15.493W
WinXP, 3DMARK2000 &
CPUBURN, mean
+12V 0.4A 4.8W
+5V 1.47A 7.35W
+3V3 1.54A 5.08W
-12V 0A 0W
5VSB 0A 0W
Total 17.232W
WinXP, 3DMARK2000 &
CPUBURN, peak
+12V 0.61A 7.32W
+5V 2.1A 10.5W
+3V3 1.64A 5.41W
-12V 0A 0W
5VSB 0A 0W
Total 23.232W
S1, mean +12V 0.25A 3W
+5V 1.05A 5.25W
+3V3 0.75A 2.48W
-12V 0A 0W
5VSB 0A 0W
Total 10.73W
S3, mean +12V 0A 0W
+5V 0A 0W
+3V3 0A 0W
-12V 0A 0W
5VSB 0.18A 0.9W
Total 0.9W
S4, mean +12V 0A 0W
+5V 0A 0W
+3V3 0A 0W
+-12V 0A 0W
5VSB 0.18A 0.9W
Total 0.9W
Inrush, peak +12V 1.54A
+5V 1.02A
+3V3 1.2A
-12V 0.09A
5VSB 3.5A
