4.6.2 CF Connector (CF)
This connector is mounted on the backside of the 986LCD-M/mITX only. If a Compact Flash Disk is used,
only one IDE device is supported on the IDE_P connector. The CF socket support DMA/UDMA CF modules.
CF is only available on some versions of 986LCD-M/mITX (PN 810200 and PN 810203). Please notice that
PCIe x16 is not available on the versions 810200-45xx-R18 and 810203-45xx-R18 and later revisions.
Note
Pull
U/D
Ioh/Iol
Type
Signal
PIN
Signal
Type
Ioh/Iol
Pull
U/D
Note
2
-
-
-
NC
26
1
GND
PWR
-
-
1
-
TBD
IO
DA11
27
2
DB3
IO
TBD
-
-
TBD
IO
DA12
28
3
DB4
IO
TBD
-
-
TBD
IO
DA13
29
4
DB5
IO
TBD
-
-
TBD
IO
DA14
30
5
DB6
IO
TBD
-
-
TBD
IO
DA15
31
6
DB7
IO
TBD
-
-
TBD
O
HDCSA1#
32
7
HDCSA0#
O
TBD
-
-
-
-
NC
33
8
GND
PWR
-
-
-
TBD
O
IORA#
34
9
GND
PWR
-
-
-
TBD
O
IOWA#
35 10
GND
PWR
-
-
-
-
PWR
5V
36 11
GND
PWR
-
-
8K2
-
I
HDIRQA
37 12
GND
PWR
-
-
-
-
PWR
5V
38 13
5V
PWR
-
-
-
-
PWR
GND
39 14
GND
PWR
-
-
-
-
-
NC
40 15
GND
PWR
-
-
-
TBD
O
RESET_C# 41 16
GND
PWR
-
-
4K7
-
I
IORDYA
42 17
GND
PWR
-
-
-
-
I
DDRQA
43 18
DAA2
O
-
-
-
-
O
DDACKA#
44 19
DAA1
O
-
-
-
-
I
HDACTA#
45 20
DAA0
O
-
-
-
-
I
CBLIDA#
46 21
DB0
IO
TBD
-
-
TBD
IO
DB8
47 22
DB1
IO
TBD
-
-
TBD
IO
DB9
48 23
DB2
IO
TBD
-
-
TBD
IO
DB10
49 24
NC
1
-
-
PWR
GND
50 25
NC
-
-
-
2
Note 1: Pin is longer than average length of the other pins.
Note 2: Pin is shorter than average length of the other pins.
