986LCD-M Family
KTD-N0837-B Public User Manual Date: 2012-04-17 Page 75 of 91
8.3.9 Advanced settings – APM Configuration
Feature Options Description
Power Management/APM Disabled
Enabled Enable or disable APM.
Video Power Down Mode Suspend
Disabled * Power Down video in Suspend or Standby Mode
Hard Disk Power Down
Mode Suspend
Disabled * Power Down Hard Disk in Suspend or Standby
Mode
Suspend Time Out Disabled,
1 Min, 2 Min, 4 Min,
8 Min, 10 Min, 20 Min,
30 Min, 40 Min, 50 Min,
60 Min Go into Suspend in the specified Time.
PS/2 Kbd/Mouse S4/S5
Wake Disabled
Enabled Enabled: System can be waked from S4 or S5.
Disabled: PS2 Kbd/Mse can still wake system
from S3.
Keyboard Wake Hotkey Any Key
“SPACE”
“ENTER”
“Sleep button” Any Key
“SPACE”
“ENTER”
“Sleep button”
Power Button Mode ON/OFF
Suspend Go into On/Off or Suspend when Power button is
pressed.
Resume On Ring Disabled
Enabled Disabled/Enable RI to generate a wake event.
Resume On PME# Disabled
Enabled Disabled/Enable PME to generate a wake event.
See note below.
Resume On RTC Alarm Disabled
Enabled Disabled/Enable RTC to generate a wake event.
RTC Alarm Date (Days) 15 Key In “+” / “-“ to select.
RTC Alarm Time 12:30:30 Use [ENTER], [TAB] or [SHIFT-TAB] to select a
field.
Use [+] or [-] to configure system Time.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
APM Configuration
Power Management/APM [Enabled]
Video Power Down Mode [Suspend]
Hard Disk Power Down Mode [Suspend]
Suspend Time Out [Disabled]
PS/2 Kbd/Mouse S4/S5 Wake [Disabled]
Keyboard Wake Hotkey [Any key]
Power Button Mode [On/Off]
ADVANCED RESUME EVENT CONTROLS
Resume On Ring [Disabled]
Resume On PME# [Disabled]
Resume on RTC Alarm [Disabled]
Enable or Disable
APM .
<- Select Screen
|| Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
