986LCD-M Family
KTD-N0837-B Public User Manual Date: 2012-04-17 Page 80 of 91
8.4 PCIPnP Menu
BIOS SETUP UTILITY
PCIPnP
Advanced PCI/PnP Settings NO: lets the BIOS
configure all the
devices in the system.
YES: lets the
operating system
configure Plug and
Play (PnP) devices not
required for boot if
your system has a Plug
and Play operating
system.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
Warning: Setting wrong values in below sections
May cause system to malfunction.
Plug & Play O/S [No]
Allocate IRQ to PCI VGA [Yes]
PCI Slot-1 IRQ Preference [Auto]
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
Plug & Play O/S No
Yes NO: lets the BIOS configure all the devices in
the system.
YES: lets the operating system configure Plug
and Play (PnP) devices not required for boot if
your system has a Plug and Play operating
system.
Allocate IRQ to PCI VGA Yes
No YES: Assigns IRQ to PCI VGA card if card
request IRQ.
NO: Does not assign IRQ to PCI VGA card
even if card request an IRQ.
PCI Slot-1 IRQ Preference Auto
3, 4, 5, 7, 9, 10, 11, 12,
14, 15 Manual IRQ selection. Not a guaranteed
selection. COM and LPT setup has
precendence over this setting.
