986LCD-M Family
KTD-N0837-B Public User Manual Date: 2012-04-17 Page 82 of 91
Feature Options Description
Quick Boot Enabled
Disabled Allows BIOS to skip certain test while booting in
order to decrease boot time.
Quiet Boot Disabled
Enabled
Black Screen
White Screen Disabled: Displays normal POST messages.
Enabled: Displays OEM Logo.
Black Screen: Displays black picture (noting).
White Screen: Display white picture.
Long Splash Disabled
WinXP ™
Vista ™ (Long Splash only available if Quiet Boot).
WinXP ™: Boot logo until WinXP boots.
Vista ™: Boot logo until Vista boots.
AddOn ROM Display Mode Force BIOS
Keep current Set display mode for Option ROM.
Bootup Num-Lock Off
On Select Power-on state for numlock
PS/2 Mouse Support Disabled
Enabled
Auto Select support for PS/2 Mouse.
Wait for ‘F1’ If Error (see note) Disabled
Enabled Wait for F1 key to be pressed if error occurs.
Hit ‘DEL’ Message Display Disabled
Enabled Displays “Press DEL to run Setup” in POST.
Lock Keyboard before OS boot Disabled
Enabled
Allow F11 popup Disabled
Enabled
Interrupt 19 Capture Disabled
Enabled Allows option ROMs to trap interrupt 19.
Execute OEM extention Disabled
Enabled
Default init boot order 0->4->3->5->2->1
0->4->3->5->1->2
1->2->3->5->0->4
3->5->1->2->0->4
3->0->4->1->2->5
2->1->0->4->3->5
2->0->4->3->1->5
3->1->0->4->2->5 The numbers in the sequence means:
0 = “Removables”
1 = “Hard Disk”
2 = “ATAPI CDROM”
3 = “BEV/onboard LAN”
4 = “USB”
5 = “External LAN”
Force boot Device Disabled
Primary IDE Master
Primary IDE Slave
Secondari IDE Master
Secondary IDE Slave
Third IDE Master
Third IDE Slave
Network Does overwrite current boot setting. Device
must be in the boot priority menu though. If the
device fails to boot, the system will not try other
devices.
Note: List of errors:
Pressed
Primary Master Hard Disk Error PCI I/O conflict
Timer Error S.M.A.R.T HDD Error PCI ROM conflict
Interrupt Controller-1 error Cache Memory Error PCI IRQ conflict
Keyboard/Interface Error DMA Controller Error PCI IRQ routing table error
Halt on Invalid Time/Date Resource Conflict
NVRAM Bad Static Resource Conflict
