Hi Gain page – from this screen it is possible to set the Output Level of the Rms High
Compressor + Peak High Limiter cascade from -12dB to +6dB, press ENTER an arrow will appear
on the left of the screen “->” then use the “Param.2” or “Param.3” buttons.
The value set on this screen will only affect the output level of the selected Rms High Compressor
+ Peak High Limiter cascade.
The following is an example screen for the “Hi Gain” page where the Hi Gain is set to +0.0dB
Hi Phase page – from this page it is possible to set the Output Polarity of the Rms High
Compressor + Peak High Limiter cascade, by using the “Param.2” or “Param.3” encoders.
The polarity can be “Normal” or “Inverted” (which means rotated of 180 Degrees).
The following is an example of a “Hi Phase” screen where the Polarity of Output Channel 1 is set
to “Normal”
Hi Vu-Meter page – from this page it is possible to select what is shown on the Output LED
meters of the coupled channels, by using the “Param.2” or “Param.3” encoders.
The outputs' LED meters can show the Output signal LEVEL (same on both coupled channels), the
Output RMS Compressors activity (High Compressor's Activity on the ODD channel's led) or the
Output Peak Limiters' activity (High Limiter's Activity on the ODD channel's led).
When the Output signal Level is selected, the LED meters will show, from bottom up, the Level of
the signal:
When the RMS High Compressor's activity is selected, the LED meters will show, from top to
down, the activity of the RMS High Compressor on the output
When the Peak High Limiter's activity is selected, the LED meters will show, from top to down, the
activity of the Peak High Limiter on the output
Out-1 Name Hi Phase
-> Polarity = Normal
Out-1 Name Hi Vu-Meter
-> Vu-Meter = Limiter Act
Out-1 Name Hi Vu-Meter
-> Vu-Meter = Level
Out-1 Name Hi Vu-Meter
-> Vu-Meter = RMS Cmp Act
Out-1 Name Hi Gain
-> Gain = + 0.0dB
