FBT DLM26 User Manual
Page 48
RMS Cmp sub-menu [2/2] – from this page it is possible to set the Attack Time. Release Time
and “Knee” type of the Output Channels RMS Compressor.
The following is an example screen for the Limiter page where the Attack Time of the RMS
Compressor is set at
10ms
, the Release Time is set at 0.2Sec and the Knee type is at the 50%
between the HARD (000%) and the SOFT (100%) one:
Once pushing ENTER the RMS Compressor's parameters can be modified using the
“NAV/Param.1”, “Param.2” and “Param.3” encoders for editing the RMS Compressor's Attack Time
[A]., Release Time [R] and Knee type.
Once pushing ENTER the above screen will change as follows:
The Attack Time [A] can be edited using the “NAV/Param.1” encoder, the Release Time [R] the
“Param.2” encoder and the Knee type the “Param.3” encoder.
“Attack Time [A]”: the selectable range of the RMS Compressor's Attack Time is from 10ms to
4s.
The Limiter's Attack Time can be adjusted by rotating the “NAV/Param.1” encoder.
“Release Time [R]”: the selectable range of the RMS Compressor's Release Time is from 0.1s to
3s in steps of 0.1s and can be adjusted by rotating the “Param.2” encoder.
“Hard/Soft Knee”: the selectable range of the RMS Compressor's Knee type is from 000%
(Hard) up to 100% (Soft) and can be adjusted by rotating the “Param.3” encoder.
Peak Limiter sub-menu – from this page it is possible to set the Output Channels Peak Limiter.
The following is an example screen for the Peak Limiter page where the Attack Time of the Peak
Limiter is set at 5ms, the Release Time is set at 0.2Sec and the Peak Limiter Active Threshold is
set at +15dB:
Once pushing ENTER the Peak Limiter's parameters can be modified using the “NAV/Param.1”,
“Param.2” and “Param.3” encoders for editing the Peak Limiter's Attack Time [A]., Release Time
[R] and Active Threshold.
Once pushing ENTER the above screen will change as follows:
Out-1 Name Limiter
A: 5ms R: 0.2s +15.0dB
Out-1 Name Limiter
-> A: 5ms R: 0.2s +15.0dB
Out-1 Name RMS Cmp
A:
10ms
R: 0.2s Kn=50%
Out-1 Name RMS Cmp
->A: 5ms R: 0.2s Kn=50%
