Principles of Operation

|

31

Sensitivity

Probe sensitivity in microamperes depends on the sensitivity in microvolts of the
receiving equipment with which it is used. The following tables show the
relationship of receiving sensitivity in microvolts to the overall sensitivity of the
probe and receiver in microamperes. This data is based on the transfer
impedance of each model.

M

ODEL

91197

S

ERIES

T

YPICAL

S

ENSITIVITY

Test Equipment Sensitivity

in Microvolts

91197-1

Z

T

= 0.33

4

12.1

2

6.0

1

3.0

0.1

0.3

M

ODEL

91550

S

ERIES

T

YPICAL

S

ENSITIVITY

Test

Equipment

Sensitivity

in Microvolts

91550-1

Z

T

= 5.0

91550-2

Z

T

= 1.0

91550-5

Z

T

= 1.0

5

1

5

5

2

0.4

2

2

1

0.2

1

1

0.1

0.02

0.1

0.1
