background image

Specifications

|

13

3.0 Specifications

At the lower frequencies, the signal current I

P

level can be as great as

allowed for maximum power current. When both signal and power
currents are high, their sum should not exceed the given limits.

L model current probes are calibrated down to 20 Hz.

Model 91197 Series Current Probe

M

ODEL

91197

S

ERIES

P

HYSICAL

S

PECIFICATIONS

Window Diameter:

3.18 cm

1.25 in

Outside Diameter:

8.26 cm

3.25 in

Width:

3.56 cm

1.4 in

Output Connector:

Type N

Weight:

0.6 kg

1 lb 5 oz

Impedance:

50
