22

|

Specifications

94106-1

Maximum Power

Current

(400 Hz):

200 amps

Maximum Power

Voltage:

No limitation; subject to adequate conductor insulation

Rated Output Load

Impedance:

50 Ω

Sensitivity Under

Rated Load:

0.1 microampere with 1 microvolt sensitivity receiver
and 10 ohm transfer impedance

M

ODEL

94106

S

ERIES

P

ULSE

P

OWER

L

IMITS

94106-1 / 94106-1L

RF Current Range

(Pulse):

50 amps

Maximum Power

Current

(L Models Only):

• (DC to 60 Hz) 300 amps

• (DC to 120 Hz) 300 amps

• (DC to 400 Hz) 300 amps

• (DC to 1500 Hz) 300 amps

When both signal and power currents are high, their
sum should not exceed the given limits
