ETS-Lindgren 94606-6 Current Probe User Manual
Page 27

Specifications
|
27
Model 94606 Series Current Probe
M
ODEL
94606
S
ERIES
P
HYSICAL
S
PECIFICATIONS
Window Diameter:
12.7 cm
5.0 in
Outside Diameter:
19.81 cm
7.8 in
Width:
5.38 cm
2.12 in
Output Connector:
Type N
Weight:
3.18 kg
7.0 lb
Impedance:
50
Ω
M
ODEL
94606
S
ERIES
E
LECTRICAL
S
PECIFICATIONS
94606-1
94606-6
Frequency Range
(L Models 20 HZ):
10 kHz–100 MHz
1 kHz–5 MHz
Transfer
Impedance
(Nominal):
5 Ω ±4dB
@1 MHz–100 MHz
1 Ω ±2dB
@10 kHz–5 MHz
RF Current Range
(RF CW):
0 amps–100 amps
0 amps–300 amps
RF Current Range
(Pulse):
0 amps–100 amps
0 amps–400 amps
Maximum Power
Current
(DC–60 Hz)
(400 Hz):
350 amps
350 amps
