ETS-Lindgren 94606-6 Current Probe User Manual

Page 14

background image

14

|

Specifications

M

ODEL

91197

S

ERIES

E

LECTRICAL

S

PECIFICATIONS

91197-1

91197-1L

Frequency Range

(L Models 20 Hz):

10 kHz–8 MHz

20 kHz–8 MHz

Transfer Impedance

(Nominal):

0.32 Ω ± 2 dB

10 kHz–1 MHz

0.32 Ω ± 2 dB

1 kHz–1 MHz

RF Current Range

(RF CW):

100 amps

• >20 kHz–150 amps max

• 10 kHz–166 amps max

• 4 kHz–200 amps max

• 2 kHz–250 amps max

• 1 kHz–400 amps max

• 400 Hz–1000 amps ma

Below 400 Hz the probe is
limited by core saturation
effects at an I

P

of

1000 amps

RF Current Range

(Pulse):

100 amps
(200 amps with reduced
duty cycle)

100 amps
(200 amps with reduced
duty cycle)

Maximum Power

Current

(DC-400 Hz):

350 amps

1000 amps

Maximum Power

Voltage:

No limitation; subject to adequate conductor insulation

Sensitivity Under

Rated Load:

30 microamperes with
1 microvolt sensitivity
receiver and 0.33 ohm
transfer impedance

30 microamperes with
1 microvolt sensitivity
receiver and 0.33 ohm
transfer impedance
