ETS-Lindgren 94606-6 Current Probe User Manual
Page 21

Specifications
|
21
Model 94106 Series Current Probe
M
ODEL
94106
S
ERIES
P
HYSICAL
S
PECIFICATIONS
Window Diameter:
3.18 cm
1.25 in
Outside Diameter:
8.26 cm
3.25 in
Width:
3.56 cm
1.4 in
Output Connector:
Type N
Weight:
0.43 kg
15 oz
Impedance:
50
Ω
M
ODEL
94106
S
ERIES
E
LECTRICAL
S
PECIFICATIONS
94106-1
Frequency Range
(L Models 20 Hz):
100 kHz–450 MHz
Transfer Impedance
(Nominal):
• 2
Ω (6 db) ± 3 dB @ 1 MHz
• 6
Ω (15.5 db) ± 3 dB @ 100 MHz—450 MHz
RF Current Range
(RF CW):
20 amps
RF Current Range
(Pulse):
50 amps
Maximum Power
Current
(DC–60 Hz):
200 amps
