Specifications

|

15

Model 91550 Series Current Probe

M

ODEL

91550

S

ERIES

P

HYSICAL

S

PECIFICATIONS

Window Diameter:

3.18 cm

1.25 in

Outside Diameter:

8.89 cm

3.5 in

Width:

7.29 cm

2.87 in

Output Connector:

Type N

Weight:

0.6 kg

1.31 lb

Impedance:

50

M

ODEL

91550

S

ERIES

E

LECTRICAL

S

PECIFICATIONS

91550-1

91550-2

91550-5

Frequency Range

(L Models 20 Hz):

10 kHz–100 MHz

10 kHz–150 MHz 10 kHz–200 MHz

Transfer Impedance

(Nominal):

5.0 Ω ± 3 dB
1 MHz–100 MHz

1.0 Ω ± 2 dB
1 MHz–150 MHz

1.0 Ω ± 2 dB
1 MHz–100 MHz

RF Current Range

(RF CW):

42 amps

2.8 amps

2.3 amps

RF Current Range

(Pulse):

100 amps

100 amps

100 amps

Maximum Power

Current

(DC–60 Hz):

350 amps

350 amps

350 amps
