26

|

Specifications

94430-1 / 94430-1L

Maximum Power

Voltage:

No limitation; subject to adequate conductor insulation

Sensitivity Under

Rated Load:

0.125 microampere with 1 microvolt sensitivity receiver
and 8 ohm transfer impedance

M

ODEL

94430

S

ERIES

P

ULSE

P

OWER

L

IMITS

94430-1 / 94430-1L

RF Current Range

(Pulse):

Pulse signals with peak currents to 70 amps can be
measured if the pulse duty cycle does not exceed:

• (16 amps I

P

) 1.0 Duty

• (25 amps I

P

) 0.625 Duty

• (40 amps I

P

) 0.39 Duty

• (50 amps I

P

) 0.3125 Duty

• (70 amps I

P

) 0.227 Duty

Maximum Power

Current

(L Models Only):

(DC to 1500 Hz) 400 amps
