ETS-Lindgren 94606-6 Current Probe User Manual
Page 18

18
|
Specifications
Model 93511 Series Current Probe
M
ODEL
93511
S
ERIES
P
HYSICAL
S
PECIFICATIONS
Window Diameter:
3.18 cm
1.25 in
Outside Diameter:
8.26 cm
3.25 in
Width:
3.56 cm
1.4 in
Output Connector:
Type N
Weight:
0.6 kg
1 lb 5 oz
Impedance:
50
Ω
M
ODEL
93511
S
ERIES
E
LECTRICAL
S
PECIFICATIONS
93511-1
93511-1L
Frequency Range
(L Models 20 Hz):
10 kHz–30 MHz
20 kHz–30 MHz
Transfer Impedance
(Nominal):
1 Ω (0 db) ± 2 dB
100 kHz–10 MHz
1 Ω (0 db) ± 2 dB
100 kHz–10 MHz
RF Current Range
(RF CW):
100 amps
100 amps
RF Current Range
(Pulse):
200 amps
200 amps
Maximum Power
Current
(DC–60 Hz):
350 amps
800 amps
