26
Replacing the Front Cover
If the front cover accidentally becomes detached from the printer,
use the following procedure to replace it.
1. Connect the power cord, AC adaptor, and USB cable to the printer,
and connect the USB cable to your PC.
Note
See page 21 for more information about making connections.
2. Press the Eject button on the front of the printer.
This causes the disc tray to come out par t way.
3. Gently pull out the disc tray.
Note
See pages 23 and 24 for details about how to per form steps 2
and 3.
4. While bending the cover guides on the left and right inward,
insert the front cover spindles on either side between the printer
case and cover guides.
5. Insert the spindles until they enter the holes provided in the printer
cover.
To replace the ink ribbon cassette
1. Press the Eject button on the front of the printer.
This causes the disc tray to come out par t way.
Important!
Make sure there is nothing in front of the printer to interfere with
movement of the disc tray.
2. Gently pull out the disc tray.
3. Open the front cover.
4. Taking care that the carriage does not move, grasp the ink ribbon
cassette on either side with your fingers and pull it towards you.
5. Install another ink ribbon cassette.
Storing a Partially Used Ink Ribbon Cassette
Install a stopper on the partially used ink ribbon cassette, place the
cassette into its plastic bag, and then into its box. Store it where it
will not be exposed to dirt and dust.
Number of Prints Per Ink Ribbon Cassette
• Upper or Lower Label Only:
Approximately 40 prints
• U p p e r a n d L o w e r L a b e l :
Approximately 20 prints
Spindle
Cover guide
Printer case
Upper label
Lower label
