24
4. Gently pull out the disc tray as shown below.
Important!
• Never use excessive force when pulling the tray.
• Do not press down on the tray with excessive force. Doing so can
damage the tray.
• If you accidentally pull the disc tray out so far that it detaches from
the printer unit, carefully replace the end of the tray onto the rail.
5. Open the front cover.
Important!
Do not apply excessive force to the ribbon winder shaft. Doing so can
cause the shaft to bend.
Before using the printer for the first time...
When you purchase the printer, the carrier is secured in place by
packing materials at the locations shown in the illustration below.
Important!
Be sure to perform the procedures from page 18 through page 24
of this manual before removing the packing material.
Carefully pull out the packing materials in the direction
indicated by the arrows.
Important!
Never perform any of the following actions while the car riage pack-
ing material is in place. Doing so creates the risk of printer malfunc-
tion.
• Continually pressing the Eject button on the front of the printer.
• Continually clicking the button on the CD/DVD LABEL PRINTER
application main window.
• Print operation.
Disc tray
Ribbon winder shaft
Front Cover
