2
Parts Inventory
The table below lists all parts in the kit. If you have trouble identifying any of these items, consult the
K2 Owner's manual, which has photographs of similar parts.
Ref. Description Part # Qty.
Components on K160RX Module
C4,C5,C6
Ca pa c i t or , . 001 µF di s c or monol i t hi c ( “ 102” )
E530001 3
C1,C3
Ca pa c i t or , 1500 pF NPO or C0G, monol i t hi c ( “ 152” )
E530002 2
C2 Ca pa c i t or , 2700 pF NPO or C0G, monol i t hi c ( “ 272” ) E530003 1
K1,K2 DPDT latching relay, 5 V (“ G6HU-2” ) E640001 2
L1,L2 Toroidal inductor, approx. 5 µH, 21 turns on T44-1 or T50-1
core (blue). (Either a T50-1 or T44-1 core can be used with the
same no. of turns.) E680001 2
P1 Conn., 16 pin male, 0.1" spcg., gold E620002 1
MISC #26 enamel wire E760002 3 ft.
MISC #24, Wire, Insulated, Stranded E760001 6 in.
MISC PC Board, K160RX E100088 1
Components on RF Board
C68 Capacitor, 10 pF NPO disc E530006 1
C153 Capacitor, 68 pF NPO disc E530007 1
C75
Ca pa c i t or , 470 pF NPO di s c or monol i t hi c ( “ 471” )
E530004 1
C13,C14 Capacitor, 1200 pF NPO disc or monolithic ( “ 122” ) E530005 2
J14 Conn., 16 pin female, 0.1" spcg., gold E620003 1
Hardware and Miscellaneous
K160-J1 Panel-mount BNC connector E620001 1
HDWR #4 split lock washer (includes 3 spares) E700004 8
HDWR 4-40 x 1/4" ZN ST phillips machine screw E700005 2
HDWR 3/16" dia. x 5/8" long round 4-40 threaded standoff E700003 1
