M O D E L 2 0 0 I P X / 2 5 0 I P X U P G R A D E
Model 200iPX/250iPX Upgrade Specifications
Version 1 Model 200iPX/250iPX Upgrade Installation Guide
1-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MODEL 200IPX/250IPX UPGRADE SPECIFICATIONS
The following specifications and requirements will help you set up your dyno area for
the 200iPX/250iPX upgrade.
Refer to the model 200iP/250iP installation guide for specifications and requirements
for the bike dyno.
C HASSIS S PECIFICATIONS
description specifications
Length
dyno with standard carriage allow 304.80 cm (120.00 in.)
dyno with extended carriage allow 355.60 cm (140.00 in.)
iPX drum module 76.20 cm (30.00 in.)
pit covers 137.16 cm (54.00 in.)
Height
from bottom of dyno to top of dyno 45.72 - 46.67 cm (18.00 - 18.38 in)
from top of pit to drum guard 5.40 cm (2.13 in)
from top of pit to top of tire carriage 50.64 cm (16.00 in)
Width
dyno with upgrade 271.42 cm (106.86 in)
pit covers 310.29 cm (122.16 in)
Weight
200iPX/250iPX drum module/crated 136 kg (300 pounds)/363 kg (800 pounds)
Drum
diameter, 200iPX/250iPX upgrade 45.72 cm (18.00 inches)
width, 200iPX/250iPX upgrade 55.88 cm (22.00 inches)
Frame structural steel
Maximum Speed 322 KPH (200 MPH)
Maximum Motorcycle Length (front of
front wheel to center of rear wheel)
standard carriage 213 cm (84.00 inches)
extended carriage 256.54 cm (101.00 inches)
Remote Switches remote software control
