03 trim preparation – Detex 02AN Trim User Manual
Page 2
Tailpiece
(see table below)
Sold separately
Tailpiece Used
Door Thickness
1-3/4" and 2" Thick Doors
2-1/4" Thick Doors
Tools Required
Power Drill
Safety Glasses
Screw Driver
Center Punch
Tape Measure
Hammer
Pencil
Cut
cylinder
tailpiece
1-1/16" (Min)
1-1/8" (Max)
2
101324 Page 2
Install
Tailpiece Assembly
Rim Cylinder
Preparation
1
Install
Trim Unit on Door
(see next page)
3
03 Trim Preparation
(No cylinder prep necessary for 02 & 01 Trims)
