Operation of these keys changes with the
software installed in the WI-127 (standard,
in-motion).
Annunciators
8
Function Keys – These oval keys along the right side of the display face
are configurable and are labeled F1, F2, and F3. The default configurations
for these keys are:
F1 Accesses tare registers
F2 Views and edits ID
F3 Accesses cutoff registers
Keypad Keys – These are the twelve square keys which support numeric
entry. The keyboard keys are labelled 0-9, plus/minus (+/-), and decimal
point (.) and are located near the center of the display face.
Directional Keys – The directional keys are used to navigate through the
WI-127's menus. These keys are labeled ESCAPE (up), ENTER (down),
(left), and MENU (right) and are positioned in a compass-like
cluster on the display face. These directional keys are denoted by the small
transparent arrows located next to them. ESCAPE, ENTER, and
also support numeric entry.
ESCAPE – Exits a menu parameter without saving any changes.
ENTER – Used to end digit entry, accept a change made, or select an item
from a function list.
– Backspaces (deletes the last digit or punctuation mark entered)
while in numeric entry and moves left within a menu.
MENU – Accesses menus and moves right within a menu.
The WI-127 has fourteen annunciators.
GROSS – Illuminates when indicator is in gross weighing mode.
TARE – Illuminates when viewing tare values in the various tare registers.
NET – Illuminates when indicator is in net weighing mode.
LB, KG, OTHER – Illuminates the active unit of measure in weighing mode.
PRINT – Illuminates when the indicator is transmitting data.
ZERO – Illuminates when the scale is within the configured center of zero.
MOTION – Illuminates when the scale detects motion (within configured
motion window).
UNDER, ACCEPT, OVER, CUTOFF, ID – Specific application
annunciators.
!
!
!
