Caution – Attwood Battery Tray User Manual
Page 2
3.
Drill eight pilot holes for the screws. Do not drill through the bottom
of the boat.
4.
Fasten down the tray using the #10 screws and washers.
5.
Place the battery into the tray.
6.
Thread a bolt into the crossbar on each side. The bolts fit tightly
to prevent them from becoming lost when changing batteries. Install
the battery retainer and bolts (see Figure 1). Tighten moderately
until bolts and/or crossbar bend slightly.
CAUTION
Overtightening the bolts could damage the threads or damage
the crossbar.
7.
Connect the battery cables, following the battery manufacturer’s
requirements for correct installation.
The positive terminal should
be insulated to prevent accidental shorting.
Battery
Battery
Retaining Crossbar
Bolt
Screws
Wa
shers
Suitable Hull
Mounting Material
Figure 1
