Attwood Lift Ring - Manual

WARNING
Lift rings are designed to lift a boat only when fastened to the boat structure. The maximum
lifting load figures listed are determined by applying a test load in the direction of the eye
shank axis, with the shank fixed in an immovable testing device. Listed lifting loads are
for reference only. No guarantee of actual lifting performance is made.
Attwood’s new stern-mounted lift ring provides heavy-duty strength for boats lifted by davits,
cranes or shore stations. Lifts a maximum vertical load of 12,000 lbs. Installs with 1/2" slotted
or hex flat countersunk stainless steel screws which must be through bolted with stainless
steel washers (1.5" minimum O.D.) and nylock nuts.
66120 Form No. 69348 Rev. B 03-11
3
®
© 2003 Attwood Corporation
1016 N. Monroe Street, Lowell, MI 49331-0260 www.attwoodmarine.com
