9090, 9091

Installation Instructions

Attwood marine hardware, navigational lighting, bilge pumps, and other

marine accessories are specified more than any other brand by America’s

best-known boat manufacturers as original equipment. Look to Attwood

for quality replacement parts and marine accessories.

SAVE THESE INSTRUCTIONS

Form Number 69222 Rev. B

04-07

Attwood Battery Hold-Down Trays are designed to be used with

standard batteries (24/24M and 27/27M series) including Gould

800 and Delco Voyager.

The adjustable-height crossbar holds the battery in place. Mounting

holes in the tray make it easy to secure and prevent battery movement.

The tray is made of noncorrosive, heavy-duty black plastic.

Meets ABYC Standard E-10 and U.S. Coast Guard requirements.

T

OOLS AND MATERIALS REQUIRED FOR INSTALLATION

1.

Drill and a suitable drill bit

2.

Eight #10 stainless steel wood/sheet metal pan head screws

3.

Eight #10 stainless steel flat washers

4.

Screwdriver

MOUNTING INSTRUCTIONS

CAUTION

Battery must be located in a well ventilated area to prevent buildup

of explosive gasses. To prevent acid burns, locate in an area away

from casual contact.

1.

Determine a suitable location for the battery tray making sure

there is enough room to work.

2.

Using the battery tray as a template, mark the location of the screw

holes. It is recommended that you use the mounting holes closest

to the retaining bolt threads, if possible. You may wish to further

secure the tray with additional screws.
